Talsa TALSA 30L Piston Stuffer with Digital Portioning and Horn Twisting Qty: 1

The new Talsa FPT30e digital automatic filler / dosing / horn twister has been designed for medium size processors who need to fill and precisely portion a wide variety of food products with a single machine. 30-liter barrel capacity allows the production of medium or small batches without waste and quick product changeover.

AT WORK:
• Various assistance systems help the user to find the most efficient way to the desired product.
• Intuitive calibrating system to produce exact weight portions in relation to the density of the product.
• Horn adjustable twisting, manual casing hold.
• Clear visual indication of remaining product.
• Counters for batch/total number and weight.

FILLING MECHANICS:
• 3 working modes: straight fill, portion, and twist.
• Single or continuous operation, programable number of portions for automatic stop.
• Portions from 5 g up to 25 kg, very precise: only ± 1 g
• Very fast, can produce up to hundreds of portions per minute.
• Number of horn twists adjustable from 1-15 revs.
• Programable fill break.

S/S FRAME:
• Very robust construction.
• Frame in all AISI304 stainless steel, external and internal, as well as hardware and possible components.
• Polished surfaces without corners, with CE radius to facilitate cleaning and comply with hygiene standards.
• Double sealed waterproof access panels.
• Closed machine bottom. • Adjustable, stainless steel machine feet, non-slip and vibration absorbing.

HYDRAULICS, ELECTRICS AND ELECTRONICS:
• Powerful motor, high hydraulic pressure, for the densest or coldest products.
• Temperature-controlled oil-cooling system
• Easy access to electric panel. • Hydraulic/electric components of first brands Hydac Germany and Schneider Electric. • Very reliable and precise electronic internal digital communications using advanced new IO-Link industry standard components Balluff Germany brand.

SOFTWARE AND EXTERNAL CONNECTIONS:
• Control panel with large 15” Schneider Electric digital touch screen, all information displayed simultaneously and in large size. Extensive information on controls, alarms, errors, and diagnostics.
• Very advanced and practical software with numerous options. Intuitive, and easy to use.
• Interactive recipes, can be stored and executed directly on the machine's screen.
• Industry 4.0 digital solutions for maintenance, process integration, and custom solutions.
• Remote Service and Support access over a secure internet connection (ethernet cable or mobile phone).

STANDARD DELIVERED WITH:
• 5 horns: 14, 20, 30, 38, and 43 mm.
• Hydraulic oil
• S/s piston extraction wrench.
